The rise of the Galleries🌌

By now I hope most people know the https://pcf.gallery (run by Guido Preite). A great page for sharing community components (PCF) and exposing awesome contributions to the rest of the world. 🌎

What I like about the PCF Gallery is the simplicity of the site only being about PCF components. This is why I asked Guido if we could create a similar site for other components regarding the Power Platform. He was so kind to share his code for the project, so Matt Beard and I decided to give it a go. 🤗

Connector Gallery

First out in list of future galleries is the CONNECTOR gallery . This site will contain all sorts of custom connectors for Power Platform that you can share with the community. If you want to contribute to this gallery, you only have to share the custom connector file you have on GitHub, and we will post it out!

Dynamics 365 Case add new contact missing

Recently I had this happen twice without really knowing why. The add new contact button was missing on the case form. In the old UI it was present, but in the new UI it was gone.

Problem

Luckily support found out that this is caused by the contact field containing some old “metadata”. All you have to do is remove it and add it back.

FIX

As you see here we have added the same field twice.. Now you can remove the “OLD” contact field and then publish..

Voila!

A pretty random thing to happen, but an easy fix:)

Dynamics / Dataverse Environment Variables in Power Automate

There have been several posts on the environment variables, but I think Microsoft just released a pretty GREAT update recently. I honestly don’t have a clue when this function was released, but it made my day a LOT easier:) This is how we used to refer to Environmental Variables:

Using Environment Variables in Dynamics 365 CRM – Part 1 | Microsoft Dynamics 365 CRM Tips and Tricks (inogic.com)

Using Environment Variables in Dynamics 365 CRM – Part 2 | Microsoft Dynamics 365 CRM Tips and Tricks (inogic.com)

Basics

When moving solutions from system A to system B we often have hardcoded values in workflows/flows/javascripts etc. These cause problems because the fields often have different values in each environment.

Sure you can migrate variables/records between systems and be sure to never overwrite, but it can be time consuming to maintain.

Microsoft has introduced environmental variables to Dynamics / Dataverse to fix this exact problem. You create a new Environmental variable in your solution, and you can se the value for each environment. Within CRM you can refer to the environmental variable instead of hardcoded values:)

Within the solution explorer you can add Environmental variables that can be used across the different systems. In this test I am using a variable to define what environment I am working in “Test or Production”.

I wont be writing about the Environment variables in detail, as you can read more about them in other posts, but I wanted to cover the new way of using this within Power Automate!

Accessing the Environmental Variables in Power Automate Flow

Start by creating a new Power Automate, and add compose function

Check out that bad boy! 🤗😎 No longer need for get record calls from entities etc. A nice improvement that will save a few minutes here and there.

Power Automate – finding Dataverse environment URL

There are many ways of getting the current environment URL, but this is the quick and dirty version of doing just this 😏 Next week I will post about Environment variables as I know this is a possible approach that is better.

The intention about this blog is to show how to use Json to parse just a small part of an action body to get what you want exposed.

Power Automate

So this could be a typical flow in Power Automate for Dataverse. We have a trigger on top and an action below to get more data from the element that triggered.

The BODY of the trigger doesn’t contain environment information, but only Opportunity data:

But the Action contains a lot more interesting data for this.

In order to get this data we need to parse the Json returned here to retrieve the “Odata.ID” that includes the URL for our environment.

{
    "type": "object",
    "properties": {
        "@@odata.id": {
            "type": "string"
        }
    }
}

Now you can store the string returned in a String Variable

Running the Power Automate

When you run the Power Automate the the variable Environment will now include the URL of the system running. From here you can use string variables in a formula like:

IF “Environment contains org.crm4” etc.

In my next post I will show how the environmental variables functionality in Dataverse / Dynamics, and how we can use this for the same purpose 😀

Dynamics 365 Teams Document Locations – Where art thou?🤷‍♂️

Even though we all wish it wasn’t so, Document Locations still rule the integrations between Dynamics 365 and SharePoint. I’m not saying that I have a better idea what would be a smarter way of solving it, but it all seems a bit “2011” ish.

Last week I encountered a problem with the Document Locations for Teams, and I was surprised when I couldn’t find them in the Document Locations at first. The list only contained the SharePoint sites that the standard SharePoint connector uses.

In this list I was missing all of the Teams locations. Turns out that the view is only showing Active SHAREPOINT locations.. hehe

All you have to do is add the “MS TEAMS” to the search, and you should see all of the document locations for that also

Dynamics 365 + Teams integration error

Recently ran into a problem with the Teams integration OOTB, where the integration continuously threw an error after connecting the Dynamics record to the Teams.

This is a pretty Vanilla environment, so I couldn’t quite figure out what was wrong. I obviously could see that the URL was wrong, but I didn’t understand WHY it was wrong.

https://**.sharepoint.com/sites/SuperCards/Shared%20Documents/General <- Nothing really wrong with this URL at first site.

After a lot of painful digging I finally found the issue. Someone had decided to install SharePoint in Norwegian when they first setup the tenant!!! hehe. This meant that the URL the SharePoint URL was wrong.

Wrong URL ⛔

Correct URL ✅

Solution?

Microsoft Support didn’t see a fix in the near future for language support, so I guess it’s time for a small work around 🙂 Not really exciting fix, but you need to create a Workflow or Power Automate on create to change the name of the document location to your local language.

Why a workflow you may ask? When is the last time a workflow failed you I answer 😎

Dynamics / Power Apps + Office App Launcher

Launching a new app or launching a new CRM system always leaves the users with the same question. Where do I find the application? At first I didn’t really understand the question, because I thought it was natural to bookmark the URL to your application ie https://www.company.crm4.dynamics.com/***** etc.

Eventually I realized that most users are actually using the waffle menu in office 365 when navigating to applications that they don’t use continuously.

They were expecting to see the application in the list when you clicked the waffle menu, because this would save them time.

Luckily this is not a problem 😊 Open the all apps, and locate the app you are looking for

And just like that you now have a quick navigation to your CRM or Power App application in the Microsoft 365 app launcher👊

Dynamics 365 form or advanced find images error

This post is almost not relevant any more due to the fact that we all will be pushed into the make.powerapps experience in “the fullness of time”, but I will still be using the classic viewer for the foreseeable future 🙂

From time to the images can get distorted due to unknown reasons. This is not a big deal as the buttons still work, but can be annoying for the users. You might have seen this in the 2 places:

Advanced find:

Advanced Find Menu Error – Microsoft Dynamics CRM Forum Community Forum

Form configuration:

Fix

There seem to be several ways to solve this issue, but not all seem to work the same. I have seen some options describing a cache clear in the console of the browser, but for some reason none of those worked for me. Lately I have had to open the developer tools and delete a bit more manual.

Click F12 in the browser where you see the error

Open the Application tab on the dev tools

Clear or delete anything within the storage related to dynamics.

Try to restart the browser, and hopefully that should do the trick:)

ACDC 2021 – Final delivery

My last post described the ACDC hackathon and what it’s all about, but this post is what our company ended up delivering for the Arctic Cloud Developer Challenge after 2 1/2 days of pure geeking 💪

Meet the Team

Area: Microsoft 365, SharePoint, Developer, Power Apps

Areas: Dynamics 365, Power Apps, Developer,

Areas: Microsoft 365, Azure, Developer

Areas: Power BI, Data Platform, Power Apps

Areas: Dynamics 365, Power Apps, Power Platform

Welcome to LEGO CITY

Our idea was to create an interconnected city with bleeding edge technology for monitoring the status quo of the citizens safety. The City is built next to a mountain that recently has been showing signs of activity. Geologist say that it could blow at any time. Luckily the city has invested heavily in technology that could help them save lives ❤

The city has a train track surrounding a lake. The Train track is crucial for transporting the LEGO’s around, and providing transportation for factories producing parts. In the city you have a Mayor’s office, LEGO factory, houses, and THE MOUNTAIN OF DOOM!! 🔥 Based on this drawing, or mission was to create the technology needed to make the city a safe place to live.

On the day of the event we started building right away, and this is what we created within a few hours😅

But since this is a technical blog, I will get into the makings of the Connected Lego City details, that made this project on of the coolest city concepts I have seen in a while!

The technology

Mountain of DOOM!!🔥

Let’s start at the top near the mountain. We placed 2 IOT sensors for monitoring temperature, and movement. We used the Azure IOT dev kit sensors for this purpose. Both IOT sensors were pushing data to Azure IOT hub, and then over to Stream Analytics. The constant changes were reported to the Majors office. The impressive part here was

Train Track Switch

On the top left we connected an Arduino device with a servo Switch connected. This was used to change the train track from long track, to short track.

By sending a boolean to the device, it would mechanically change the trains direction. You can barely see the device hidden beneath the track with a wire for power under the blue “water”. To see it in action, just watch the video on top.

Majors Office – Command Central

In the bottom left we had the majors office (aka command central), where the major could minor all thigs happening in his city. This is where we were looking at the output from the city sensors, and reporting via Stream Analytics to Power BI.

We included Dynamcis 365 information on the left to give a status on all ongoing city work orders (fixing problems), and on the right side we had live data from the mountain. One of the charts were showing the constant temperature, and others were measuring movement. Below we connected to the Norwegian weather API, so that we could understand what potential conditions would effect our emergency response the next days.

Train conductor – remote worker

During these Corona times we wanted to give the Train Conductor the possibility to work from home. Therefore we mounted a camera on the train, and connected it to a Raspberry PI. The Raspberry PI was also running a piece of software that could control the USB part of the LEGO Boost. For this we combined projects from:
1: https://motion-project.github.io/motion_config.html
2: https://github.com/virantha/bricknil

We also created a webserver running the live feed of the camera with the controls. The conductor could then log in and power the train in any direction needed 🚆🚂

Citizen Self Service

When there was an issue in the City, the citizens could report this via porta to Dynamics Customer Service. We connected with The Portal Connector for this scenario.

Submitting the case would deliver the case to Dynamics 365 Customer Service, where we used a few PCF components from pcf.gallery for picture rendering in CRM.

LEGO Factory – Field Service

Once the case had been evaluated, we would create a work order for booking our trusted technician for the job. For this case we used Field Service OOTB, and the technician would used the new mobile app for service delivery. We also connected the warehouse for picking parts from the factory based on the initial pictures that the technician would have seen.

Payment – Vipps

The technician fixed the broken houses, he would then send an invoice via the Norwegian payment service Vipps. The awesome thing about this was that it was all done by using a Power Automate Flow for the job! Once the Work Order was complete, we simply created a payment for the Vipps API, and received our money.

Crisis team

If the IOT sensors detected crisis, they would start a flow that the mayor would have to approve.

From this flow we would also trigger sending of SMS notification to the citizens that were in dataverse.

ACDC 2021 – Hackathon summary

WOW… Simply WOW. It’s the best way to summarize this years hackathon.

Normally this 3 day hackathon is situated in the beautiful hill of Holmenkollen, but this year we were forced to go online for obvious reasons. One little difference we did do was to open up for teams to gather locally at their companies offices. This way we could add a social factor within safety regulations without having to keep everyone 100% at home office.

We decided to have a participation fee for the event, and everything that was extra would be given to children’s cancer www.barnekreftforeningen.no

This project has consumed most of my time the last few months being a part of the committee, and getting it all together has not been easy.

We were 5 teams total and almost 40 participants that dedicated 3 whole days of fun where this years topic was LEGO.

ACDC 2021 (arcticclouddeveloperchallenge.net) <- Homepage for the hackathon with the live scores

Teams were from:
Point Taken (Point Taken Brixters)
Avanade (Orange Panthers)
Albatross (The Merge Conflict)
Skill (Klossmajorene)
Felleskjøpet (Cowders)

Arctic Cloud Developer Challenge Submissions (acdc.blog) <- The blog showing most things that were created during the 3 days.

Our team decided to create a Lego City where IOT sensors controlled it all. I will write more about the geek stuff in my next post, but this might give you some hint:

Winner of the tournament was Felleskjøpet, that simply were superior in this years technical setup and performance. Read more about their solutions in the ACDC BLOG!! 🙂

Final delivery – Cowders | Arctic Cloud Developer Challenge Submissions (acdc.blog)

Charity

While everything is fun and games, we were able to raise some money as well! 🙌✨🙌

This event just really made my day, and I am thankful for the People that made it happen. Amazing what community can do when we work together!

Ulrikke Akerbæk (Skill)
Carlos Briceno (Bouvet)
Marius Børresen (Felleskjøpet)
Jarle Engseth (Skill)
Ragnhild Baumann (Infoworker)
Thomas Sandsør (Point Taken)
