On-Premise Data Gateway setup

So the On-Premise data Gateway itself might not be the most awesome thing in history, but in combination with the data integration of PowerApps it is just incredible! Carina wrote about this earlier, but I had to see it for myself 🙂

My example is based on the need to integrate my On-Prem ERP (SQL) server with Dynamics 365 online (aka PowerApps).

This method does require that you have username/password credentials to a view in SQL that will allow you to read data. After the setup, Part 2 – Final Finnish.

I need data from On-premise to Online

I needed to integrate my ERP system (On-Premise) to D365 in the cloud. There are several ways to complete this normally with code, SSIS, Scribe etc. I wanted to learn what the PowerPlatform was capable of.

I am not a developer, so I am always seeking for solutions considered No-Code, Low-Code. Integrations was something I always had to involve developers to complete.

Until now!!

Installing software

Install latest Onprem Gateway software – Be sure to update this from time to time due to function/feature/security updates from Microsoft.

The software should be installed on a server, because of the need for 24/7 uptime. While testing, you can easily install the software on your personal computer as long as it is in the same network as the SQL database you are trying to connect to.

Open the software, and set it up. I chose to use my login credentials for this action. These credentials where also the ones that were “creators” in Dynamics.

Remember the Gateway Name and Password

When this is done you should find the Gateway in your PowerApps.
NB!!! It will only install under the Default instance for now!!

Check connection with PowerApps

Last step is to open up your browser to PowerApps and see if we can retrieve the data. Open PowerApps

Make sure you navigate to the Dynamics Production environment

Then you open a new integration project

From here you connect to the On-Prem SQL DataGateway.
Don’t worry, the credentials and IP are not real here:)

So the important thing on the next step is to use the credentials for your SQL server. These credentials only need to be read from a database. This means that you might have to ask someone to create read credentials for your database.

Choose the tables you want to sync. Debitor is Accounts in our ERP system.

If you are lucky, you will see the following result!! You are now one step closer to actually complete a NO-Code integration with an onprem SQL server.

HOW COOL IS THAT!!!!!

Part 2 Final Integration

Dynamics 365 – Teams. Love at first SITE (pun intended)..

The Team

Hi everyone, meet Knut and Kjetil.

Knut is a salesperson at Point Taken. He just came across a HUGE deal that he has registered in Dynamics 365. This deal is so big that Knut will need the assistance of several resources to deliver. One of these resources is Kjetil, a SharePoint consultant.

The setup

Knut enters the details needed for the Dynamics 365 deal

Knowing that this opportunity is HUGE, Knut starts by creating a new channel in the Offers Team (name is “General” for demo purposes).

The connection

Knut has now setup the structure for collaboration, and is ready to connect Teams and Dynamics 365 together.
Well done KNUT!! 🙂

Add the Dynamics 365 connection for the tab in the channel

Knut chooses the correct opportunity record.

When Knut is done, he can see the newly created connection message in Teams. The above message indicates that Teams and Dynamics successfully connected.

The harmony begins

Kjetil begins right away with the PowerPoint they will need to win this deal. Kjetil does not have a license for Dynamics, so he creates the PowerPoint in Teams because this is the natural place for collaboration.

Knut can now choose to navigate Teams or Dynamcis 365, because the systems are working with the same document location.

Knut and Kjetil represent 2 different work processes, but are harmonizing well when referring to the ONE TRUTH document. Well done you to!!!

Dynamics and Teams in perfect harmony!

Dynamics 365 – Teams Configuration

The configuration of the client is pretty straight forward. A typical office product, and that is a good thing:) FYI, it does not install a solution file within Dynamics, and I like that a lot… Never been a fan of the overcrowding of solution files (Hint hint portals.. hehe).

Start pÃ¥ opening the system settings from Dynamics and locating the “Enable Dynamics and Teams integration”.

NB! Before starting, I would create a new Team and a new channel just for the sake of simplicity. Also create a new record in CRM that you want to connect to.

It took me about 3 minutes before I received my complete message, so be patient!

Open teams and locate the App Store within teams and search Dynamics. You will find it on the “…” menu on the left side.

Add to the team you created. In my case “Tilbud” and then click Open

Next step is connecting it to the channel in the team, and hit “Set up”.

Now it will ask you for an entity to connect to, so I am going to choose the Opportunity I created before I started the configuration “Teams Opportunity”.

If it all went well, you will now see a new tab in your channel with the name of the record. You also see a message that the record is connected.

The result

Dynamics and Teams working together

Dynamics 365 + SharePoint. Why is this still an problem?

Microsoft has used words like “seamlessly” integrated when speaking about Dynamics 365 and SharePoint, and I have hated it since day one. CRM and SharePoint never seemed to get it right, and after a while I feel they just gave up. The current state of the integration is in most cases utterly useless.

Larger companies

The larger companies will require scalability and security. The integration has none of these in combination. The standard integration has absolutely no idea what security is, and therefore opens all documents for everyone with site access. In larger organizations they might want to separate the BU’s or even more granular access like team access in CRM. This is where you have to use 3rd party tools like Connecting Software. The second you start adding security to folders, you will hit the cap of 50k something unique permissions in a DocLib.

Result: Fail

Smaller companies

The smaller companies have the highest requirements in regards to simplicity. They expect it to be easy to drag/drop files, navigate a simple folder structure, merge documents from CRM that end up in the SP folder etc. In general the smaller companies are always benchmarking the CRM system against smaller collaboration solutions, and therefore expect simple usage. Again the standard isn’t enough.

Result: Fail

Microsoft Teams, the new hope

So with the introduction of Teams + Dynamics integration, we might be somewhat closer to a solution for collaboration that could work. For the first time it makes sense to include others outside of Dynamics 365 to collaborate on the documents. A salesperson could now easily work together with others in the organization that don’t have the Dynamics license. I will show you how in a later blogpost.

Does this mean that we can use the word “seamless” in regards to integration? NOPE, but we are one step closer. My biggest concern is still that the product teams working on this seem to be forgetting to solve the simple features. When you merge a document out of Dynamics, it should be easy to put it back in to Dynamics (SP folder) where it belongs! We should need to have solutions like Documents Core Pack or Xperido for the simple templates.

Anyway. Stay tuned for the next blog when I show how cool the new integration with Teams is:)


CDS vs Dynamics Connector Power Platform

There are several discussions regarding the use of CDS connector VS the Dynamics connector in the Power Platform. Recently I have been updating my knowledge a lot on PowerApps, PowerBI and Flow. The odd thing is that these environments behave quite different even thought they are so closely connected in regards to connectors.

how much longer will they co exist, and why are they even different?

So here are my thoughts about the current state April 2019 (this might be outdated in one month 😂)

Flow CDS vs Dynamics 1 – 0

https://crmtipoftheday.com/1177/use-the-cds-connector-when-you-go-with-the-flow/
When using Flow, the CDS connector seems to be the correct choice. I personally feel that the action advanced settings is the most important reason why the CDS would be the correct choice.

CDS connector will only run the flow if country is changed saving you the flow, and the Dynamics connector will run no mater what costing you 1 flow.

PowerBI CDS vs Dynamics 2 – 0


https://www.inogic.com/blog/2018/10/connect-to-the-power-bi-using-common-data-service-cds/
There are maybe many reasons why you would choose the CDS connector over the Dynamics connector for API reasons, but the most important one I like to focus on is the Option Set (Pick List) from Dynamics.

Look at the Yellow columns. They show the display name of the Options Set, so no more need for hacks to convert the fetch from numbers to names. Obviously a huge benefit that this solution will update when the Option Set values update also!

PowerApps CDS vs Dynamics 2 – 1

But wait… It might not be over yet. While tampering with lookup controls for PowerApps I found out that CDS simply doesn’t have the lookup fields in the data!

CDS connector (Simply doesn’t have any lookups):

Dynamics Connector (With lookups):

Data presented is still in a GUID state, but there is a workaround for that:)

https://www.inogic.com/blog/2018/07/working-on-lookup-field-of-dynamics-365-in-powerapps/ <– How to fix GUID in PowerApps
